Full control of a WLED device from your Twitch & Discord events. Power, brightness, colour, effects, palettes, presets, playlists, nightlight — plus ready-made party effects like Flashbang, Blink, Strobe and Police lights. Point it at your WLED's IP and wire any event to your LEDs in the action builder.
> Works with any WLED device on your local network (ESP8266/ESP32) over its built-in JSON API.


What you need
- A WLED device on the same local network as your PC, with a known IP address
  (e.g. 192.168.1.50). Tip: give it a static IP / DHCP reservation in your router so it doesn't change.
- aiostool running and connected to your bot.
- Nothing to enable on the device — WLED's JSON API is on by default.


Setup
1. Install the **WLED** mod from the mod section and push it to your device (or, as a developer, open the
   folder in the Dev area).
2. Open the mod's **settings** and enter your **WLED IP address**.
3. In the action builder, add an **aiostool Action**, pick your device, choose **WLED**, then the action
   you want — the parameters appear as a form.
That's it. Trigger it from a follow, sub, cheer, channel-point redemption, a command… anything.


Basic controls
Action
What it does
Key parameters
Power on/off/toggle
Turn the lights on, off, or toggle
state, optional brightness, transition_ms
Set brightness
Overall brightness
level (1–255)
Set colour
Solid colour (shows even over a running effect)
hex (#33ccff) or r/g/b, optional brightness, segment
Set effect
Any WLED effect by id
effect_id, optional speed, intensity, palette, segment
Set palette
Colour palette by id
palette_id, optional segment
Apply preset
A saved WLED preset
preset_id
Start playlist
A saved WLED playlist
playlist_id
Nightlight
Nightlight timer
on, duration (min), mode (0–3), target_brightness
Set default transition
Crossfade time for future changes
ms
Raw JSON state
Anything the actions above don't cover — send raw /json/state
json
Get device info
Read name, version, LED count
-
Get current state
Read power/brightness/segments
-
> Effect and palette ids are the ones shown in the WLED app (Effects/Palettes lists). Use Get current state if you want to see what's active.


Special effects 🎉
These are the fun ones for stream alerts. The colour effects switch the segment to solid so the
colour actually shows, and the momentary ones snapshot your current state and restore it afterwards
(including the effect that was running).


Action
What it does
Flashbang
A quick full-brightness white flash, then back to how it was
Colour flash
Same, but in a colour you choose
Blink
Blink a colour on/off for a short duration
Strobe
Very fast blinking of a colour/white
Police lights
Alternating red/blue
Fade to colour
Smoothly crossfade to a colour over a set time
Pulse / breathe
Continuous breathing of a colour (runs until you change it)
Rainbow
Continuous rainbow (runs until you change it)


Example ideas
- New follower → Colour flash in your brand colour.
- Raid → Police lights for a few seconds, then back to normal.
- Bits / Cheer → Flashbang scaled to the amount.
- Channel-point "party" → Rainbow; a second redemption sets it back with Set effect or Set colour.
- Sub → Fade to gold, then Pulse.


Good to know
Momentary effects are time-capped (~3 seconds). Flashbang, Blink, Strobe and Police run *during* the action, so they're bounded so they can't stall. For long, continuous blinking use Set effect with WLED's own Blink/Strobe effect instead.
"Set colour" forces Solid. If an effect was running, setting a colour switches the segment to solid so the colour is visible. Want to keep an effect and just change its colour? Use Set effect / Set palette.
Segments. Colour/effect/palette actions take an optional `segment` id if you run multiple segments; leave it blank to target the whole strip.
Can't reach the device? If an action reports "Set the WLED device IP…" the IP isn't set in the mod settings. If it's set but nothing happens, check the IP is correct and reachable from your PC — open `http://<your-wled-ip>/json/state` in a browser to confirm.


Support
Found a bug or want another effect? Reply below. 💡
